Overview:

Graphics Processor: RV535

Pxl : Vtx : TMUs : ROPs
12 : 5 : 4 : 4

Memory Size: 256 MB D2
Memory Bus: 128 bit
Manufacturer: HIS
Original Series: Radeon X1K
Released After: August 23rd, 2006

Graphics Processing Unit:

GPU Model: RV535
Architecture: ATI R500
Fabrication Process: 80 nm
Die Size: 131 mm2
Transistors Count: 330M
Transistors Density: 2.5M TRAN/mm2
Pixel Pipelines: 12
Vertex Pipelines: 5
TMUs: 4
ROPs: 4

Clocks:

Base Clock: 600 MHz
Memory Clock: 400 MHz
Effective Memory Clock: 800 Mbps

Memory Configuration:

Memory Size: 256 MB
Memory Type: DDR2
Memory Bus Width: 128-bit
Memory Bandwidth: 12.8 GB/s

Physical:

Interface: PCI-Express 1.0 x16
TDP/TBP: 44 W

API Support:
DirectX: 9.0c
Vulkan: -
OpenGL: 2.0
OpenCL: -

Performance:
Pixel Fillrate: 2.4 GPixels/s
Texture Fillrate: 2.4 GTexel/s
